68 Technical Bulletin—TC-9100 Universal Controller
Item Type MEM R/W Tag Description
Hex Dec
Programmable Module 4
48 72 Number D W PM4K1 Constant K1
49 73 Connection D WP PM4I1@ Input Connection I1
4A 74 Connection D WP PM4I2@ Input Connection I2
4B 75 Connection D WP PM4I3@ Input Connection I3
4C 76 2 Bytes D WP PM4TY
P
Options
4D 77 Number D WP PM4K2 Constant K2
4E 78 Number D WP PM4K3 Constant K3
4F 79 Number D WP PM4K4 Constant K4
50 80 Number D WP PM4K5 Constant K5
51 81 Number D WP PM4K6 Constant K6
52 82 Number D WP PM4K7 Constant K7
Programmable Module 5
53 83 Number D W PM5K1 Constant K1
54 84 Connection D WP PM5I1@ Input Connection I1
55 85 Connection D WP PM5I2@ Input Connection I2
56 86 Connection D WP PM5I3@ Input Connection I3
57 87 2 Bytes D WP PM5TY
P
Options
58 88 Number D WP PM5K2 Constant K2
59 89 Number D WP PM5K3 Constant K3
5A 90 Number D WP PM5K4 Constant K4
5B 91 Number D WP PM5K5 Constant K5
5C 92 Number D WP PM5K6 Constant K6
5D 93 Number D WP PM5K7 Constant K7
Programmable Module 6
5E 94 Number D W PM6K1 Constant K1
5F 95 Connection D WP PM6I1@ Input Connection I1
60 96 Connection D WP PM6I2@ Input Connection I2
61 97 Connection D WP PM6I3@ Input Connection I3
62 98 2 Bytes D WP PM6TY
P
Options
63 99 Number D WP PM6K2 Constant K2
64 100 Number D WP PM6K3 Constant K3
65 101 Number D WP PM6K4 Constant K4
66 102 Number D WP PM6K5 Constant K5
67 103 Number D WP PM6K6 Constant K6
68 104 Number D WP PM6K7 Constant K7
