Technical Bulletin—TC-9100 Universal Controller 29
PM Tag
(Cont.)
Alg
Tag
Type Description
PMxTYP TYP 2 Bytes
Algorithm Options define the behaviour of the
programmable module.
Bits 5…1
Algorithm Number in binary code:
00001 = Algorithm 1.
⇓
00110 = Algorithm 6.
Bit 6
Enable Low Limit (Anti-freeze) Override for this
module:
0 = Not enabled.
1 = Output set to 100% when low limit active
(AFM=1).
Bit 7
Enable Summer Compensation for this module:
0 = Not enabled.
1 = WSP increased by the Summer Compensation
value SAC (Item Address 1D hex).
Bit 8
Enable Winter Compensation for this module:
0 = Not enabled.
1 = WSP increased/decreased by the Winter
Compensation value WAC (Item Address 1C
hex).
Bit 9
Enable OFF Override for this module:
0 = Not enabled.
1 = When the controller is in OFF mode, the output
is set to 0% or the Low Limit value (LOL –
PI controller only), whichever is lower.
Bit 10
Enable Manual OFF Fan Override for this module:
0 = Not enabled.
1 = If “3-speed fan control” is configured in OCN5,
the output of the controller is set to 0 % or Low
Limit value (whichever is lower) when the fan is
set to OFF by an override connection to OCN6
or by a TM-9180 Room Command Module.
Do not set this bit if the controller is
connected to Output Module OCN5.
Bit 11
Enable Startup Override for this module:
0 = Not enabled.
1 = When the controller is commanded to start up
by a supervisory system, the output is set to the
level specified by the Startup Output Level (Bit
12).
Bit 12
Startup Output Level for this module:
0 = Startup output level is 0% or Low Limit value
(whichever is lower).
1 = Startup output level is 100%.
Continued on next page...
