Metos PROVENO E - Construction of the Combi-Kettle

12
|
PROVENO E
Rev. 1.2 (24.08.2016)
Safety
2.2. Construction of the combi-kettle
The main parts of the combi-kettle are illustrated in the following pictures:
1. Support pillar
2. Safety block
3. Mixer and mixing tool
4. Emptying valve for steam generator
5. Safety lid
6. Safety grid for fi ll opening
7. One-grip tap for cleaning jet
8. Control panel
9. Emergency/stop button
10. Cleaning jet
11. Water fi ll to kettle
1
2
3
4
5
6
7
9
8
10
11
