PROVENO E
Rev. 1.2 (24.08.2016)
Technical specifi cations
Item Type Specifi cation
Overall dimensions incl. support pillar WxDxH 40,60 1047x800x900/1535 mm
Overall dimensions incl. support pillar WxDxH 80,100 1154x800x900/1535 mm
Overall dimensions incl. support pillar WxDxH 150,200 1360x920x900/1535 mm
Overall dimensions incl. support pillar WxDxH 300,400 1560x1160x900/1535 mm
Support pillar dimensions LxDxH 150x250x900 mm
Distance needed behind the kettle 40 860 mm
Distance needed behind the kettle 60 945 mm
Distance needed behind the kettle 80,100 955 mm
Distance needed behind the kettle 150 1070 mm
Distance needed behind the kettle 200 1070 mm
Distance needed behind the kettle 300,400 1270, 1280 mm
Tilting height from pouring lip edge to fl oor 40 - 400 600 mm
Maximum height of cover 40,60 1740 mm
Maximum height of cover 80,100 1745 mm
Maximum height of cover 150,200 1995 mm
Maximum height of cover 300 2110 mm
Maximum height of cover 400 2080 mm
Distance needed for service 40 - 200 450 mm
Distance needed for service 300, 400 500 mm
Inner diameter 40, 60 472 mm
Inner diameter 80,100 545 mm
Inner diameter 150,200 744 mm
Inner diameter 300,400 944 mm
Material of inner jacket and bottom Acid proof stainless steel AISI 316
Other parts of the kettle Stainless steel AISI 304
Weight with package 40 260 kg
Weight with package 60 270 kg
Weight with package 80 295 kg
Weight with package 100 325 kg
Weight with package 150 380 kg
Weight with package 200 410 kg
Weight with package 300 490 kg
Weight with package 400 550 kg
Weight 40 215 kg
Weight 60 225 kg
Weight 80 245 kg
Weight 100 280 kg
Weight 150 320 kg
Weight 200 360 kg
Weight 300 430 kg
Weight 400 490 kg
Transport volume 40 - 100 2,07
Transport volume 150,200 2,91
Transport volume 300,400 3,88
