30
|
VIKING 4G E, S
Rev. 1.0 (29.1.2020)
Installation
6.1.5. Disposal of the package
After unpacking all packing material must be sorted and disposed of in accordance with local recycling
regulations.
6.2. Installation
Check before installation from the installation drawing that there is enough space behind the kettle for
tilting and servicing. Also check the location of the fl oor drain.
The kettle is designed for installation in a place with a fl oor drain in front of the kettle. The arrangement with a
pouring channel and fl oor drain behind the kettle is not suitable for use with the kettle
The kettle can be installed in three different ways:
• On a subsurface installation frame, the frame cast into the fl oor.
• On a surface installation frame, the frame fi xed to the fl oor surface.
• Free standing
For kettles size 200 - 400 l a subsurface frame installation is recommended.
Fixing the kettle directly to the fl oor without frames is forbidden.
Either subsurface frames or surface frames must be in position before the installation of the kettle
is started.
Installation dimensions and fl oor drain placement, see ”Technical specifi cations”
6.3. Residual current device recommendation
• It is recommended to use a residual current device in the installation of a kettle as follows:
• Kettles without mixer: Type A residual current device.
• Kettles with mixer and operating voltage 200V, 230V or 400/230V: Type A residual current device
with high frequency fi ltering or a residual current device separately approved for use with frequency
converters.
• Kettles with mixer and operating voltage 380 – 480V without neutral: Type B three-phase residual
current device
