Metos VIKING - Electrical Connection Specifications

|
55
VIKING 4G E, S
Rev. 1.0 (29.1.2020)
T
echnical specifications
7.5. Electrical connections
The values of the special voltages differ from the standard voltage values.
Viking Combi
3/N/PE AC 400/230V 50 Hz
Type
Viking
Power/
kW
Current/
A
Fuse/
A
Supply cable diameter
min / mm max / mm
40E
11,5 22 25 22 32
60E
12,5 24 25 22 32
80E
14,0 26 32 22 32
100E
18,0 32 32 22 32
150E
23,6 45 50 22 32
200E
33,6 59 63 22 32
300E
43,6 74 80 34 44
400E
62,0 97 100 34 44
Viking Basic
3/N/PE AC 400/230V 50 Hz
Type
Viking
Power/
kW
Current/
A
Fuse/
A
Supply cable diameter
min / mm max /
mm
40E
9,0 13 16 22 32
60E
10,5 15 16 22 32
80E
12,0 17 20 22 32
100E
16,0 23 25 22 32
150E
20,0 29 32 22 32
200E
30,0 43 50 22 32
300E
40,0 58 63 34 44
400E
57,2 87 100 34 44
Viking Basic
2/PE AC230V 50-60Hz, 1/N/PE AC 230V 50Hz
Type
Viking
Power/
kW
Current/
A
Fuse/
A
Supply cable diameter
min / mm max / mm
40S
0,8 3 10
13 18
60S
0,8 3 10
13 18
80S
0,8 3 10
13 18
100S
0,8 3 10
13 18
150S
0,8 3 10
13 18
3NPE AC 400/230V 50Hz
Type
Viking
Power/
kW
Current/
A
Fuse/
A
Supply cable diameter
min / mm max / mm
200S
0,9 2 10
13 18
300S
0,9 2 10
13 18
400S
0,9 2 10
13 18
Electrically heated
Steam heated kettles
Viking Combi
2/PE AC230V 50-60Hz, 1/N/PE AC 230V 50Hz
Type
Viking
Power/
kW
Current/
A
Fuse/
A
Supply cable diameter
min / mm max / mm
40S
2,2 9 10
13 18
60S
2,2 9 10
13 18
80S
2,2 9 10
13 18
100S
2,2 9 10
13 18
150S
3,6 16 16
13 18
3NPE AC 400/230V 50Hz
Type
Viking
Power/
kW
Current/
A
Fuse/
A
Supply cable diameter
min / mm max / mm
200S
3,6 16 16
13 18
300S
3,6 16 16
13 18
400S
4,8 20 25
13 18
