99-2003 DASH DISASSEMBLY
11
CADILLAC • Fleetwood 1990-1996 /
Fleetwood Brougham 1990-1996
1. Carefully unsnap trim panel above a/c controls.
2. Remove (2) 7mm screws at the top of the radio/air conditioning bezel, then
unclip panel and remove.
3. Remove (4) 7mm screws that hold the radio in, slide radio out, unplug the
radio harnesses and remove radio.
4. See page 44 for all vehicle tab instructions.
Disconnect the negative battery terminal to prevent an accidental short circuit.
Continued on page 12 and 13.
