99-2003 DASH DISASSEMBLY
23
CHEVROLET • Tracker 1992-04
SUZUKI • Sidekick 1992-98 / Vitara 1999-04
1. Remove the cigarette lighter and climate control knobs.
2. Remove the ashtray and (1) screw exposed.
3. Pull out on the climate control cluster and remove (2) screws exposed.
4. Unclip the radio trim bezel.
5. Remove (4) screws from the factory head unit, slide the unit out and discon-
nect the wiring.
6. See page 44 for all vehicle tab instructions.
Disconnect the negative battery terminal to prevent an accidental short circuit.
