99-2003 DASH DISASSEMBLY
16
CHEVROLET • Express Van 2001-02 / GMC • Savanna 2001-02
1. Unsnap and remove small trim panel below steering column.
2. Unsnap radio/climate/instrument panel.
3. Move shift lever to first gear position.
4. Rotate panel counterclockwise to lift over steering column and remove.
5. Remove (3) 9/32" hex head screws to remove radio.
6. See page 44 for all vehicle tab instructions.
Disconnect the negative battery terminal to prevent an accidental short circuit.
To Next Page
