99-2003 DASH DISASSEMBLY
14
CHEVROLET • Blazer 2002-04 / S-10 2002-04
GMC • Sonoma 2002-04
OLDSMOBILE • Bravada 1998-01
1. Remove (2) 9/32" hex-head screws from the knee bolster.
2. Pull down on the bolster and remove 9/32" screws exposed on the base of
the dash trim bezel.
3. Remove (1) Phillips screw above the instrument cluster.
4. Unclip the dash trim bezel and remove.
5. Unclip the dash trim bezel and remove.
6. See page 44 for all vehicle tab instructions.
Disconnect the negative battery terminal to prevent an accidental short circuit.
