99-2003 DASH DISASSEMBLY
24
CHEVROLET • Trailblazer 2002-2009
1. Remove (2) Phillips screws inside instrument cluster.
2. Remove (1) Phillips screw under climate controls to the left of the power
outlet.
3. Remove (2) 7mm hex heads from under steering column and lower the
panel. Remove (3) Phillips screws around steering wheel.
4. Unsnap and remove bezel. (Use caution pulling over hazard switch.)
Remove (3) 7mm hex head screws to remove radio.
5. See page 44 for all vehicle tab instructions.
Disconnect the negative battery terminal to prevent an accidental short circuit.
