99-2003 DASH DISASSEMBLY
18
CHEVROLET • Impala 2000-2004
1. Unclip each side of the dash trim bezel (fuse access) and remove (1) Phillips
screw exposed on each side.
2. Remove (2) Phillips screws under the instrument cluster.
3. Unclip the trim panel above the pedals. (It is not necessary to remove the
panel, it can be left hanging.
4. Remove (2) Phillips screws from under the knee panel.
5. Unclip the knee panel and remove (1) Phillips screw exposed on the right
side of the steering column.
6. Unclip and remove the entire dash trim bezel.
7. See page 44 for all vehicle tab instructions.
Disconnect the negative battery terminal to prevent an accidental short circuit.
