99-2003 DASH DISASSEMBLY
21
CHEVROLET • Monte Carlo 2000-2004
1. Unclip the trim panel above the pedals. (It is not necessary to remove the
panel, it can remain hanging.)
2. Remove (2) 9/32" screws from the knee panel and unclip the panel.
3. Unsnap the driver's side fuse panel cover and remove (1) 9/32" screw.
4. Open the glove box and remove (1) 9/32" screw from the upper left corner.
5. Remove (3) 9/32" screws securing the factory radio and disconnect the
wiring.
6. See page 44 for all vehicle tab instructions.
Disconnect the negative battery terminal to prevent an accidental short circuit.
