99-2003 DASH DISASSEMBLY
29
1. Remove (4) Phillips screws, (2) from left and (2) from right of carpeted panel
below dash forward of center console.
2. Slide carpeted panel down and backwards to reveal (2) Phillips screws and
remove.
3. Unsnap radio bezel and unplug cigarette lighter and accessories.
4. Remove (3) 9/32" hex head screws and remove radio.
5. See page 44 for all vehicle tab instructions.
Disconnect the negative battery terminal to prevent an accidental short circuit.
GMC • Envoy 2002-09 / ISUZU • Ascender 2003-08
OLDSMOBILE • Bravada 2002-04
