99-2003 DASH DISASSEMBLY
30
OLDSMOBILE • Achieva 1996-1998
1. Open the glove box, press inward on the walls of the glove box liner and
remove the liner.
2. Remove (10) torx-head screws from the glove box location.
3. Remove (2) 9/32" hex-head screws under the steering column.
4. Unclip the dash trim bezel.
5. Remove the screws securing the factory head unit and disconnect the
wiring.
6. See page 44 for all vehicle tab instructions.
Disconnect the negative battery terminal to prevent an accidental short circuit.
