99-2003 DASH DISASSEMBLY
3
BUICK • Century 1997-04 / Regal 1997 - 04
1. Open both doors and remove end caps from both ends of dashboard.
2. Open glove box, then remove (1) 9/32" screw from panel above passenge
kick panel and remove.
3. Remove 9/32" screws from bottom left and right of ashtray assembly
and unclip and remove.
4. Unclip top edge of panel below steering column and let hang.
5. Remove (1) 9/32" screw from right side of instrument cluster and
radio trimpanel and remove entire panel from right to left.
6. Remove (3) 9/32" screws to remove radio.
7. See page 44 for all vehicle tab instructions.
Disconnect the negative battery terminal to prevent an accidental short circuit.
