99-2003 DASH DISASSEMBLY
BUICK • Rendezvous 2002-2005
1. Open center console and remove (2) Torx T-15 screws at front of console
opening.
2. Remove liners from cup holders and storage pocket next to cup holders,
then remove (4) Torx T-15 screws. Unsnap and remove panel.
3. Remove (2) 7mm hex head screws from bottom of driver side dash panel and
remove.
4. Unclip dash panel and remove.
5. Remove (3) 9/32" hex head screws to remove radio.
6. See page 44 for all vehicle tab instructions.
Disconnect the negative battery terminal to prevent an accidental short circuit.
6
