99-2003 DASH DISASSEMBLY
BUICK • LeSabre 2000-04 / Park Avenue 2000-04
1. Open drivers door and unsnap and remove dash end cap.
2. Remove (2) Phillips screws from underneath steering column cover.
3. Unsnap and remove steering column cover.
4. Unsnap and remove instrument panel.
5. Remove (2) 9/32" screws and remove radio.
6. See page 44 for all vehicle tab instructions.
Disconnect the negative battery terminal to prevent an accidental short circuit.
NOTE: For the Buick Le Sabre, Oldsmobile Aurora and the Pontiac Bonneville
the (3) speed clips and screws provided with the kit will need to be installed
into the sub dash where the screw holes line up on the kit.
5
