99-2003 DASH DISASSEMBLY
28
HUMMER • H2 2003-2004
Disconnect the negative battery terminal to prevent an accidental short circuit.
7. Remove (1) 10mm bolt to right of shift lever.
8. Remove (2) phillips screws from under console box on drivers side and (2)
phillips screws from under console trimtop on passenger side.
9. Slide control assembly rearwards.
10. Remove (2) T-30 torx bolts from top of rado/climate control trim and
unclip and remove.
11. Remove (3) 9/32” screws that hold the radio in.
12. See page 44 for all vehicle tab instructions.7
