99-2003 DASH DISASSEMBLY
27
HUMMER • H2 2003-2004
1. Open center console and remove (4) 9/32” screws from console box and
remove box.
2. Remove (4) phillips screws from hinge on console door inside console
and remove door.
3. Loosen (1) T-15 torx on forward facing side of shift lever and pull up to
remove.
4. Unclip cup holder/shifter trim assembly and remove.
5. Remove (6) phillips screws from top of center console.
6. Remove (2) phillips screws from inside pocket on back of center console,
then unclip and remove.
Disconnect the negative battery terminal to prevent an accidental short circuit.
To Next Page
