99-2003 DASH DISASSEMBLY
CHEVROLET • SSR 2003-2006
A
B
C
D
1
Unclip and remove the long trim panel
below the radio and passenger air
bag. (Figure B)
Disconnect the negative battery
terminal to prevent an accidental
short circuit.
3
Unclip and remove the (3) climate
control knobs. (Figure A)
2
Unclip and remove the small trim
panel to the left of the steering
wheel. (Figure C)
4
Remove the (5) 9/32” screws securing
the radio/instrument panel then unclip
and remove the panel. (Figure D)
5
Remove the screws securing the
factory head unit and disconnect the
wiring.
6
Continue to kit assembly.
