99-2003 DASH DISASSEMBLY
17
CHEVROLET • Express Van 2003-04 / GMC • Savanna 2003-04
1. Remove (2) 10mm bolts from below knee bolster under steering column
and remove panel.
2. Remove (2) 10mm bolts from panel below passenger dash airbag and
remove panel.
3. Remove (2) 10mm nuts from inside center pocket between power outlets.
4. Unsnap and remove radio and instrument cluster panel. (May not be nec-
essary to completely remove radio and instrument cluster panel to access
radio.)
5. Remove (3) 9/32" bolts to remove radio.
7. See page 44 for all vehicle tab instructions.
Disconnect the negative battery terminal to prevent an accidental short circuit.

Metra Electronics 99-2003 Specifications

General

Brand	Metra Electronics
Model	99-2003
Category	Car Receiver
Language	English
