99-2003 DASH DISASSEMBLY
34
OLDSMOBILE • Eighty Eight 1994-99 / Ninety Eight 1994-96
1. Open the glove box and remove (2) hex-head screws securing the wood
trim.
2. Unsnap the wood trim and remove.
3. Remove (2) 9/32" hex-head screws below the radio trim bezel.
4. Lift up on the bezel and remove.
5. Remove (3) 9/32" hex-head screws securing the factory head unit and dis-
connect the wiring.
6. See page 44 for all vehicle tab instructions.
Disconnect the negative battery terminal to prevent an accidental short circuit.
