99-2003 DASH DISASSEMBLY
38
PONTIAC • Bonneville 2000-2004
1. Remove (2) Phillips screws from the instrument cluster.
2. Unclip the ignition trim and remove.
3. Unclip the climate control / radio trim panel and remove.
4. Depress the spring clips on each side of the factory head unit and remove.
5. See page 44 for all vehicle tab instructions.
Disconnect the negative battery terminal to prevent an accidental short circuit.
NOTE: For the Buick Le Sabre, Oldsmobile Aurora and the Pontiac Bonneville
the (3) speed clips and screws provided with the kit will need to be installed
into the sub dash where the screw holes line up on the kit.
