99-2003 DASH DISASSEMBLY
42
SUZUKI • Esteem 1995-
1. Remove the climate control knobs.
2. Remove (1) Phillips screw located above the radio opening.
3. Unclip the radio trim bezel.
4. Remove (4) screws from the factory head unit, slide the unit out and discon-
nect the wiring.
5. See page 44 for all vehicle tab instructions.
Disconnect the negative battery terminal to prevent an accidental short circuit.
To Next Page
