99-2003 KIT ASSEMBLY
46
ALL VEHICLES - DIN HEAD UNIT PROVISIONS
1. Slide DIN cage into the Housing and secure by bending metal locking tabs
outward. See Figure A
2. Slide radio into DIN cage. See Figure B
3. Skip to step #1 in the Final Assembly on page 49.
NOTE: A snap-in DIN spacer has been provided for some applications where
depth is an issue. Snap the spacer in the housing and slide DIN cage
into the assembly and secure by bending metal locking tabs down.
See Figure C
Disconnect the negative battery terminal to prevent an accidental short circuit.
