48
ALL VEHICLES - DOUBLE DIN HEAD UNIT PROVISION
1. Remove the center bar from DDIN Trimplate. See Figure A
2. Attach the DDIN / stacked ISO brackets by aligning the holes and securing
the unit to the brackets using the screws supplied with the unit.
See Figure B
3. Snap the bracket & unit assembly to the DDIN Trimplate. See Figure C
4. Skip to step #1 in the Final Assembly on page 49.
99-2003 KIT ASSEMBLY
