Metrix CX 1651 User Manual

140
No
error
label
description
troubleshooting
01
Overload 2V !
2V range overloaded
Output current is too high. Increase load resistance.
02
Overload 20V !
20 V range overloaded
Output current is too high. Increase load resistance.
03
Overload 200V !
200, 1000 V ranges
overloaded
Output current is too high. Increase load resistance.
04
Overload I
output !
Current output
overloaded
Voltage on the load is too high. Decrease load resistance.
05
High
temperature !
Too high internal
temperature
Output stages are overloaded. Do not use ranges 200V,
1000V or 20 A for at least 10 minutes. Check if the
ventilation holes are free.
06
Overload RC !
RC simulator overloaded
Test current is too high. Use lower range of tested
Ohmmeter.
07
FBK error !
Internal error
Turn off the calibrator and turn on it again.
08
OUTPUT must
be in OFF state !
Cable adapter tried to be
exchanged while output
terminals was ON
Switch off output terminals with button OUTPUT, change
the adapter, and switch output terminals on.
10
Interface error !
GPIB communication
error
Wrong data format on GPIB.
11
Bad command !
Bad command of GPIB
Not known command on GPIB.
12
Bad
communication !
GPIB communication
error
Listener not connected to the GPIB. Check correct
connection of GPIB cable.
13
Over range !
Overcrossing the range
via GPIB
Value out of range was set via GPIB. Set correct value.
20
Bad calib. code !
Bad calibration code
Wrong calibration code was entered, calibration cannot
start. Enter correct calibration code.
21
Time warm up !
Attempt to start
calibration before warm
up
Attempt to start calibration before 60 minutes warm up
period. Let the calibrator turned on for at least 60 minutes.
24
Cable adapter
must be off !
Adapter isn’t allowed for
autocalibration
Use another cable adapter or perform autocalibration
procedure without cable adapter.
25
Use cable
adapter !
Attempt to start
calibration without cable
adapter.
Calibration of resistance ranges can be performed with
adapter Option 70. Calibration of internal multimeter can be
performed with cable adapters Option 40 and Option 60.
30
Internal RxD
timeout !
Internal error
Internal error of the calibrator. Turn the calibrator off and
after 5 s turn on. If the error will appear again, contact
manufacturer.
31
Internal
communication !
Internal error
Internal error of the calibrator. Turn the calibrator off and
after 5 s turn on. If the error will appear again, contact
manufacturer.
37
Calibrator is not
ready !
Internal error
Internal error of the calibrator. Turn the calibrator off and
after 5 s turn on. If the error will appear again, contact
manufacturer.
40
Value too large !
Maximum value is out of
limit
Attempt to set value over possible range. Set correct value.
41
Value too small !
Minimum value is out of
limit
Attempt to set value under possible range. Set correct
value.
42
Deviation too
large !
Deviation is too high
Set deviation is out of limit –30% to +30%. Set correct
value.
44
Unable +/- !
Change of polarity is not
allowed
Attempt to change polarity, where it is not allowed..
Concerned modes F, P-E, R-C, ACV, ACI.
45
Unable –
polarity !
Negative polarity is not
allowed.
Attempt to set negative polarity, where it is not allowed..
Concerned modes F, P-E, R-C, ACV, ACI.
46
Unable DC/AC !
DC/AC conversion is not
possible
Attempt to change parameter AC/DC where it is nonsense
or where it is not allowed.
47
Current timeout
!
Time limit for current
over 10 A exceeded
Long-term loading current terminals with output current
over A.
48
Not allowed on
AUX output !
Function cannot be used
on output AUXILIARY
Do not use this setting in combination with connected cable
adapter.
