Metrix MTX 3250 User Manual

Technical Specifications
50,000-count Benchtop Multimeter 49
Technical Specifications
Measuring current
ADC current
In "DC" mode, users can measure a direct current value or an alternating
current’s direct component.
AAC,
AAC+DC
TRMS current
@ Note
In "AC" and "AC+DC" modes, users can measure an alternating current’s rms
value with/without its direct component (no capacitive coupling in "DC" mode).
Results < 0.2 % are not displayed.
@ Note
Specifications for direct current superimposed on a sinusoidal signal in the
40 Hz to 10 kHz band, valid from 10 to 100 % of rate.
For the mA and µA range, the "AUTO PK" mode is always active:
Additional error of 2 % for a peak factor between 1 and 1.5.
Additional error of 15 % for a peak factor between 1.5 and 2.
Peak factor is 5 for a 10 A range.
In 500 mADC and 500 mAAC+DC:
Voltage drop < 600 mV
Protection 600 Vrms per HPC ceramic-type fuse
Fuse 600 V / 10 A / 50 kA Cos ϕ > 0.9 (6.3 x 32 mm)
In 10 A and 10 AAC (or AC+DC):
Voltage drop < 300 mV
Protection 600 Vrms per HPC ceramic-type fuse
Fuse 600 V / 10 A / 50 kA, Cos ϕ > 0.9 (6.3 x 32 mm)
Fuse can be accessed outside unit.
Rate Precision Resolution
Input
resistance
Admissible
overload
500 µA 0.2% + 5D 10 nA
about 350 Ω
5 mA 0.2% + 3D 0.1 µA
about 35 Ω
50 mA 0.2% + 3D 1.0 µA
about 5 Ω
500 mA 0.2% + 5D 10.0 µA
about 0.5 Ω
10 A 0.5% + 5D 1 mA
about 0.02 Ω
Rate Precision Resolution
Input
resistance
Admissible
overload
500 µA 0.5% + 30D 10 nA
about 350 Ω
5 mA 0.5% + 30D 0.1 µA
about 35 Ω
50 mA 0.5% + 30D 1.0 µA
about 5 Ω
500 mA 0.5% + 30D 10.0 µA
about 0.5 Ω
10 A 2.5% + 30D 1 mA
about 0.02 Ω
Accuracy
40 Hz to 1 kHz 1 to 4 kHz 4 to 10 kHz
500 µA 10 nA
0.5% + 40 D typ.1%+ 40 D -
5 mA 0.1 µA
50 mA 1.0 µA
0.5% 1% 2%
500 mA 10 µA
+ 30 D + 30 D + 30 D
10 A 1 mA
- -
(cont.)
20 Arms
(30 s max.)
20 Arms
(30 s max.)
