4 Fundamentals of operation
916 Ti-Touch
￭￭￭￭￭￭￭￭
15
Table 1 Fixed keys which are always available
[Home] always opens the main dialog.
[Back] saves the entry and opens the next-higher dialog
page.
[Help] opens the online help feature for the dialog dis-
played.
[Print] opens the printing dialog.
[Manual] opens the manual control.
[Stop] cancels the ongoing determination.
[Start] starts a determination.
The method loaded, the time and the system status are displayed in the
main dialog in the Title bar.
In the other dialogs, the title bar shows the headings of the next upper
level and of the displayed dialog. This is an aid for orientation during navi-
gation through the user dialog.
Table 2 Screen elements
Buttons open a new dialog when they are tap-
ped.
Inactive buttons with gray lettering indicate
that the respective function is not available at the
moment.
Input fields open an input dialog when tapped
with the finger.
Tapping on the selection symbol opens a selec-
tion list.
A check box can also be activated or deactiva-
ted by tapping on it.
