Metrohm 930 Compact IC Flex - 3 Overview of the Instrument; Front; Figure 1 Front

3.1 Front
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
8
￭￭￭￭￭￭￭￭
930 Compact IC Flex Oven SeS/PP/Deg (2.930.2560)
3 Overview of the instrument
3.1 Front
Figure 1 Front
1
Bottle holder
2
Column holder
For hanging the separation column (iCol-
umn). With column recognition.
3
Column oven
4
Metrohm Suppressor Module (MSM)
5
Sample degasser
6
Inline filter
7
Injection valve
8
Purge valve
9
Pulsation absorber
10
Base tray
