4 Installation
930 Compact IC Flex Oven SeS/PP/Deg (2.930.2560)
￭￭￭￭￭￭￭￭
25
Setting the contact pressure correctly
1
￭ Fully loosen the contact pressure lever , i.e. press it all the way
down.
￭ In the software, activate the drive of the peristaltic pump with the
desired speed.
￭ Raise the contact pressure lever one step at a time until liquid
flows.
￭ When liquid starts flowing, raise the contact pressure lever by an
additional two ratchet increments.
The contact pressure is now set optimally.
