Table 9-5. ICD 5 Tool Opons Category
Programming Mode Entry Select programming mode entry type:
• Use high voltage program mode entry
• Use low voltage program mode entry
PGC Conguration Programming clock pin setup.
• none
• pull up
• pull down
PGC resistor value (kohms) If pull up or pull down is selected above, enter a resistor value from 0 to 50 kohms.
PGD Conguration Programming data pin setup.
• none
• pull up
• pull down
PGD resistor value (kohms) If pull up or pull down is selected above, enter a resistor value from 0 to 50 kohms.
9.2.5 Freeze Peripherals
Select peripherals to freeze, or not freeze, on program halt. Options available depend on device
chosen.
Table 9-6. Freeze Peripherals Opon Category
Freeze Peripherals Check to freeze all peripherals on halt.
Uncheck to unfreeze all peripherals.
This options applies to PIC12/16/18 MCUs.
Peripheral Freeze Enable
Peripheral List
Check to select which peripheral(s) to freeze.
Uncheck to unfreeze all peripherals.
This option applies to AC244066.
Peripheral List Check to freeze the peripheral Peripheral on halt.
Uncheck to unfreeze the peripheral Peripheral.
This options applies to 16- and 32-bit MCUs.
PIC12/16/18 MCU Devices
To freeze/unfreeze all device peripherals on halt, check/uncheck the “Freeze Peripherals” checkbox.
If your desired peripheral does not halt, be aware that some peripherals have no freeze on halt
capability and cannot be controlled by the debugger.
dsPIC, PIC24 and PIC32 Devices
To freeze/unfreeze a peripherals on halt, check/uncheck the peripheral from the list. If you do not
see a peripheral on the list, check/uncheck “Freeze All Other Peripherals.” If your desired peripheral
does not halt, be aware that some peripherals have no freeze on halt capability and cannot be
controlled by the debugger.
9.2.6 Trace and Proling
Depending on the device you have selected for your project, you may be able to use trace, PC
sampling/proling or other data collection features when debugging. Enable and set up these
features as specied in the following sections.
8-Bit and 16-Bit Devices
Options available on this page depend on the trace/proling features of the project device.
