1.0 Overview
1.2 Specifications
For detailed specifications, please see the specification sheets available on the Microhard website @
http:///www.microhardcorp.com for your specific model.
Electrical/General
Frequency: 2.402 - 2.478 GHz or
5.000 - 5.900 GHz
Link Rate: See Section 1.3 Performance Specifications
TX Power: 20 dBm - 30 dBm Total (Adjustable)
Channel Bandwidth: 1, 2, 4, 8 MHz (Selectable)
Error Detection/Control: CRC, ARQ
Data Encryption*: 128-bit AES (Optional 256-bit)
(*Requires Export Permit)
Serial Port: 300bps to 921kbps
Ethernet: Dual 10/100 BaseT, Auto - MDI/X, IEEE 802.3
USB: 2.0
Network Protocols: TCP, UDP, TCP/IP, ARP, ICMP, DHCP, HTTP, HTTPS*, SSH*,
SNMP, FTP, DNS, Serial over IP (*May require an export permit)
Operating Modes: Master, Slave/Remote, Repeater, Mesh Node
Management: Local Serial Console, Telnet, WebUI, SNMP, FTP &
Wireless Upgrade
Diagnostics: Status LED’s, RSSI, remote diagnostics, SNR
Input Voltage: OEM: Digital Voltage: 3.3 VDC (500mA)
RF Voltage: 5.0 VDC (1.5A)
Current:
2.4 GHz 5.8 GHz
MIMO ON MIMO OFF MIMO ON MIMO OFF
Tx Power
(dBm)
Vcc @
3.3V
VRF @
5V
Vcc @
3.3V
VRF @
5V
Vcc @
3.3V
VRF @
5V
Vcc @
3.3V
VRF @
5V
Peak Avg. Transmit Current (mA)
20 250 - 720 630 250 - 560 350 250 - 620 340 250 - 510 400
22 250 - 720 720 250 - 560 400 250 - 620 390 250 - 510 440
24 250 - 720 800 250 - 560 440 250 - 620 450 250 - 510 490
26 250 - 720 880 250 - 560 510 250 - 620 520 250 - 510 570
28 250 - 720 1020 250 - 560 600 250 - 620 620 250 - 510 650
30 250 - 720 1250 250 - 560 780 250 - 620 790 250 - 510 740
Instantaneous Current Draw - 500 1500 500 1500 500 1000 500 1000
Typical Receive Current Draw
(mA)
- 250-720 - 250 - 560 400 - 460 - 250 - 510
Table 1-1: pMDDL5824 Current Consumption
