4.0 Configuration
Image 4-6-3: Diag > Iperf
4.6.3 Diag > Iperf
The pMDDL5824 features an integrated Iperf server/client to use to measure and analyze throughput of
TCP/UDP packets to and/or from the pMDDL5824. Iperf is a 3rd party utility that can be loaded on any PC
to measure network performance. For additional information about Iperf, please visit the Iperf website.
The pMDDL5824 can be configured to operate as a Server, listening for an incoming connection from
another device (with Iperf), or PC running an Iperf client. If set to Iperf client, the pMDDL5824 will connect
to or send packets to a specified Iperf server.
Iperf Mode
Select between an Iperf Server (listens for incoming connections) and
client (initiates a connection with a server)
Values (selection)
Server / Client
Server Status
If the Iperf mode to set to Server, this Server Status allows a user to
Enable or Disable the server.
Values (selection)
Enable / Disable
Protocol
Select the type of packets to be sent to test the throughput. TCP packets
are connection oriented and require additional overhead for the
handshaking that occurs, while UDP is a connectionless, best effort
oriented protocol.
Values (selection)
TCP / UDP
