© Microhard 69
4.0 Configuration
Source IPs
Match incoming traffic from the specified source IP range. Boxes accept
single IP Addresses without network masks, example: 192.168.1.0 to
192.168.1.255 represents all IP Addresses in the 192.168.1.0/24 network.
(Put same IP in both boxes for a single IP match.)
Values (IP Address)
192.168.0.0 to
192.168.0.0
Destination
Select the zone which is the intended destination of the data traffic. The
selections shown will reflect any network interfaces configured.
Values (selection)
LAN/WAN/None
(varies)
Destination IPs
Match incoming traffic from the specified destination IP range. Boxes
accept single IP Addresses without network masks, example: 192.168.1.0
to 192.168.1.255 represents all IP Addresses in the 192.168.1.0/24
network. (Put same IP in both boxes for a single IP match.)
Values (IP Address)
192.168.0.0 to
192.168.0.0
Destination Port
Match incoming traffic directed at the given destination port or port range.
(To specify a port range use a From:To (100:200) format)
Values (port)
0
Protocol
The protocol field defines the transport protocol type controlled by the rule.
Values
TCP
UDP
Both
ICMP
Source
Select the zone which is to be the source of the data traffic. The LAN/WAN
refers to local connections on the pMDDL5824.
Values
LAN/WAN/Independent LAN/
USB/Any
