4.0 Configuration
IP Protocol Config (Continued…)
• Remote Port
The UDP port associated with the Remote IP Address (above). In the case of this
‘Remote’ being the Master Nano IP Series, the value in this field should match the
Listening Port of the Master (see UDP Point-to-Multipoint (P)).
Default: 20012
• Multicast IP Address
A valid MULTICAST address that this unit will use to receive multicast UDP packets sent
by a UDP Point-to-Multipoint (P) unit. Note that the default value for this field matches
the default Multicast IP Address of the UDP Point-to-Multipoint (P) configuration
described on the previous page.
Default: 224.1.1.2
• Multicast Port
The UDP port that this unit will use, along with the Multicast IP Address detailed above,
to receive the multicast UDP packets sent by the UDP Point-to-Multipoint (P) unit.
Default: 20002
• Multicast Interface
Specify the interface on which to send/listen for multicast packets.
Default: default
