Field or Button Description
Cancel [button]
Discards any changes.
Coefficients
The coefficients used in the equation.
Degree [button]
The coefficients give the n
th
order term from a polynomial fit. Coef-
ficients higher than the degree of the polynomial are not displayed.
Zero is shown for coefficients that are not determined because of an
insufficient number of included points. R
2
is the usual R-squared stat-
istic.
Fisher Number [column]
The Fisher number from an analysis run on an instrument that uses
Fisher number.
Include [checkbox]
Select to include in the fit. Errors are indicated for SAS particle sizes in
enabled rows that are not greater than zero and strictly increasing. The
graph is not updated, and Save is disabled when any fields have
errors.
Selecting a row or focusing the Fisher number field highlights the
corresponding point in the graph. Changing the selections or the
Fisher number for a selected point updates the coefficients, R
2
, and
the graph.
Include origin
[checkbox]
If selected, a point at 0, 0 is included in the line fit.
Material [drop-downbox]
Comes from the SOPs, records, and other maps. This map will be
used to determine the Fisher number for all records with the selected
material.
SASParticle Size (μm)
[column]
Enter the particle size from the analysis run on the MICSASII.
Save [button]
Saves changes.
x-axis
y-axis
The x-axis is SAS Particle Size (μm) and the y-axis is Fisher Number.
The lower axis limits are zero; the upper limits are autoscaled. The fit is
shown as a smooth curve without points in orange. A legend identifies
the two data sets.
Fisher Number Map
Fisher Number Map Report
MIC SAS II 5800 Operator Manual
580-42800-01 (Rev - ) — June 2019
3 - 7
