Field or Button
Description
Static. Select to assign specific network settings. Network
configuration is required for remote operation through a web
browser, but not necessary for operating the instrument with the
touchscreen. See Remote Computer Configuration on page6
- 5.
l IPaddress * [textbox]. Use to change the IPaddress of the instru-
ment.
l Subnet * [textbox] . Use to change the Subnet setting of the instru-
ment.
l Gateway * [textbox]. Use to change the Gateway setting of the
instrument.
Build date **
Displays the software build date.
Current local time
[textbox]
Set the instrument's clock by entering the current local date and time.
IPaddress ***
IPaddress of the instrument.
Location [textbox]
Location of the instrument.
Logo file name **
The file name of the uploaded logo.
Model **
Instrument model.
Name [textbox]
The name of the instrument (ie., lab number, etc.).
NTP [button]
Enable to use Network Time Protocol for setting the instrument's
clock. The instrument must be attached to a network with NTP
servers. If NTP is disabled, the instrument will keep time on a battery-
backed internal clock.
Piston cycles **
Indicates the number of times the piston has gone to the disengage
position after home or analysis. The number is set to zero when a force
calibration is performed. The number before the reset is logged in the
force calibration message.
Print report after ana-
lysis [checkbox]
Enable to print a report after each analysis.
Printers [button]
Click to configure a printer attached to the instrument. See Printer
Installation on page6 - 6.
Revert [button]
Returns fields to the currently saved values.
Save [button]
Saves screen changes.
Serial Number **
Serial number of the instrument.
Maintenance (continued)
6 Maintenance Menu Selection
MIC SAS II 5800 Operator Manual
580-42800-01 (Rev - ) — June 2019
6 - 3
