Connect a Gas Cylinder
Analyzer Series
Gauge should indicate
3Flex
15 psig (103 kPag)
AccuPyc
25 psig (172 kPag)
ASAP
15 psig (103 kPag)
AutoChem
15-18 psig (103 - 124 kPag)
AutoPore
50-60psig (345 - 404 kPag)
Gemini
15-18 psig (103 - 124 kPag)
MICSASII
15-20 psig (103-138 kPag)
TriStar
15-18 psig (103 - 124 kPag)
Regulator Pressure Settings
Exceeding the maximum recommended air pressure could cause personal injury or dam-
age the instrument.
Replace a Gas Cylinder
MIC SAS II 5800 Operator Manual
580-42800-01 (Rev - ) — June 2019
7 - 5
