Microsemi SyncServer S350 - Statusleds; Keypad;Display

Front Panel
n 2Tx
n 3Rx
n 4N/C
n 5GND
n 6N/C
n 7CTS
n 8RTS
n 9N/C
StatusLEDs
The four tricolor LEDs provide the following status information:
Red Orange Green Dark
Sync
SyncServer is
not synchronized
to a
reference.
NTP Stratum 16.
SyncServer is syn-
chronized to a remote
NTP server.
NTP Stratum 2-15.
SyncServer is synchronized to
an Input Reference or the
modem
1
.
NTP Stratum 1.
Power off.
Network
Link failure on the
LAN1.
Link failure on the LAN2,
LAN3, or LANGBE.
All configured ports operational. Power off.
NTP
>7000 NTP pack-
ets per second.
> 5000 packets per
second.
NTP activity within the last
second.
No NTP
activity in
the last
second.
Alarm
Major Alarm. Minor Alarm. No Current/Enabled Alarms. Power off.
Also see Stratum (on page 202).
Keypad/Display
The keypad/display displays the time, status information, and provides functions described
by Keypad/Display Interface (on page 101).
Keypad
Description:19-button firm silicone rubber keypad
Functionality:User input device
Arrow keys: Left, Right, Up, Down
Numeric keys: 0 through 9
Command keys:ENTER, CLR, TIME, STATUS, MENU
Display
Description:256 x 32 pixel vacuum fluorescent display (VFD)
Functionality:Displays time, status, and functions. User-configurable brightness levels.
1
The SyncServer S350i does not include a modem.
997-01520-02 Rev. F1.......................................................................... Page 113
