Web Interface
Field Example of Field Value
l IPv4/UDP – this is Default
l 802.3
Sync Interval "1 pkt/1 sec"
Delay Mechanism "E2E"
ITT "1"
E2E Delay Interval "1 pkt/1 sec"
P2P Delay Interval "1 pkt/1 sec"
Priority 1 "128"
Priority 2 "128"
Domain Number "0"
Announce Transmit Interval "2 sec"
Announce Timeout Multiplier "3"
STATUS - Alarms
Current Major or Minor Alarms
Alarms with Severity set to:
n Major are displayed in red text.
n Minor are displayed in orange text.
n Notify are not displayed.
Alarms can be configured using the ADMIN - Alarms page.
For each listing:
Time: The local date and time at which the alarm was raised.
Severity: The severity of the alarm event (Major/Minor).
Name: The name of the alarm, from the list of alarms on the ADMIN - Alarms page.
NETWORK - Ethernet
Use this page to get status and configure Ethernet LAN port network settings, including DNS
servers.
Ethernet Port Configuration
Edit the network port configuration and view network port status.
EDIT: Clicking this button opens a dialog box for configuring the network port.
Pending Changes: A check mark indicates that settings have changed, reminding the user
to click the APPLY button.
Port: The name of the network port.
Page 32..........................................................................997-01520-02 Rev. F1
