Midea LSBLG320/MZ - Outline Dimension

DX type water-cooled screw chiller (PCB Control) MCAC-CTSM-2014-03
12
4.Outline Dimension
Single head
Chilled Water Inlet
Chilled Water Outlet
Cooling Water Outlet
Cooling Water Inlet
Model
A
B
C
D
E
F
H
J
K
Cooling
Water
In/outlet
Chilled
Water
In/outlet
LSBLG255/MZ
2800
1165
1350
1600
880
1780
280
210
140
DN80
DN80
LSBLG320/MZ
2800
1165
1350
1600
880
1760
280
210
140
DN80
DN80
LSBLG400/MZ
2860
1285
1420
1600
1000
1780
328
246
160
DN100
DN100
LSBLG485/MZ
3200
1300
1450
1600
1000
1660
330
230
200
DN125
DN125
LSBLG630/MZ
3430
1480
1600
1800
1220
2150
360
260
200
DN125
DN125
LSBLG860/MZ
3430
1610
1730
1800
1360
2120
400
300
200
DN150
DN150
Dual heads
Chilled Water Outlet
Chilled Water Inlet
Cooling Water Outlet
Cooling Water
Inlet
Model
A
B
C
D
E
F
H
J
K
Cooling
Water
In/outlet
Chilled
Water
In/outlet
LSBLG970/MZ
4100
1630
1680
1800
1440
2120
415
290
200
DN150
DN150
LSBLG1060/MZ
4100
1740
1680
1800
1440
2680
415
290
200
DN150
DN150
LSBLG1260/MZ
4450
1780
1730
2000
1540
3080
415
285
260
DN200
DN200
LSBLG1490/MZ
4600
1810
1920
2000
1640
3080
650
340
260
DN200
DN200
NOTE: Drawings are not contractually binding. Before designing an installation, consult the certified dimensional drawings
supplied with the unit or available on request.
For the positioning of the fixing points, weight distribution and center of gravity coordinates please refer to the dimensional
drawings.
