MCAC-CTSM-2014-03 DX type water-cooled screw chiller (PCB Control)
79
G= cooling capacity×2.6L
Process type cooling
G= cooling capacity×7.4L
b. In certain occasion (especially in manufacture cooling process), for conforming the system water
content requirement, it’s necessary to mount a tank equipping with a cut-off baffle at the system to
avoid water short-circuit, Please see the following schemes:
4).Water pipeline installation
Due to the variety of piping practices, it is advisable to follow the recommendations of local
authorities. The installation and insulation of the water pipelines of the air conditioning system shall
be designed and guided by design professionals, and confirm to the corresponding provisions of the
HVAC installation specifications.
Basically, the piping should be designed with a minimum number of bends and changes in elevation
to keep system cost down and performance up.
