11.Operating Range
Content
Running range
Chilled Leaving Water Temperature
5℃～15℃
Cooling Entering water Temperature
20℃~35℃
Water flow volume
Rating flow volume ±20%
Inlet/outlet water Temp. difference
3.8℃~ 7.1℃
Fouling factor (m
2.
℃/kW)
0.086
Voltage tolerance
Rating Voltage±10%
Phase tolerance
±2 ％
Power supply frequency
Rating frequency±2%
Evaporator max working pressure on water side
1.0MPa
Compressor max. start count
4 times/h
Environment quality
High corrosive environment and high
humidity should be avoided.
Drainage system
The height of water drainage should not be
higher than the base of the unit on the spot
Normal operation ambient temperature
-10℃~45℃
Storage and transport temperature
-15℃～50℃
Applicable altitude range：
No more than 1000m
Operating limits and changes water temperature curve
LSBLG***/MZ evaporator
Minimum
Maximum
Entering temperature at start-up
12°C
35°C
Leaving temperature during operation
5°C
15°C
Entering/leaving temperature difference at full load
3.8°C
7.1°C
LSBLG***/MZ condenser
Minimum
Maximum
Entering temperature at start-up
19°C
35°C
Leaving temperature during operation
25°C
40°C
Entering/leaving temperature difference at full load
3.8°C
7.1°C
Note:
