7.1 Dimensions
7 INSTALLATION PRECAUTIONS
Model A B C D E F G H I J
4/6kW
8/10/12/14/16kW
1295
1385
397
482
429
526
760
760
265
270
105
60
225
221
792
945
161
182
/
81
4/6 kW (unit: mm)
H
8/10/12/14/16 kW (unit: mm)
I
H
J
I
E D
B
F
G
C
A
E D
B
F
C
A
Check the strength and level of the installation ground so that the unit may not cause any vibrations or noise during its
operation.
In accordance with the foundation drawing in the figure, fix the unit securely by means of foundation bolts. (Prepare four sets
each of Φ10 Expansion bolts, nuts and washers which are readily available in the market.)
Screw in the foundation bolts until their length is 20 mm from the foundation surface.
7.2 Installation requirements
(unit: mm)
Concrete
basement
h≥100mm
Rubber
shocking
proof mat
≥100
≥80
Φ10 Expansion
bolt
Solid
ground
or roofing
