Midea M-thermal Mono Series - Water Piping and Connections

9.4.1 Check the water circuit
9.4 Water piping
All piping lengths and distances have been taken into consideration.
ValveRequirements
Thermistor cable length minus 2m
The maximum allowed thermistor cable length is 20m. This is the maximum
allowable distance between the domestic hot water tank and the unit (only for
installations with a domestic hot water tank).The thermistor cable supplied with
the domestic hot water tank is 10m in length.In order to optimize efficiency we
recommend installing the 3-way valve and the domestic hot water tank as close
as possible to the unit.
If the installation is equipped with a domestic hot water tank (field supply), please refer to the domestic hot water tank
Installation And Owner's Manual. If there is no glycol (anti-freeze) in the system there is a power supply or pump failure,
drain the system (as shown in the figure below).
NOTE
If water is not removed from the system in freezing weather when unit is not used, the frozen water may damage the
water circle parts.
NOTE
29
The unit is equipped with a water inlet and water outlet for connection to a water circuit. This circuit must be provided by a
licensed technician and must comply with local laws and regulations.
The unit is only to be used in a closed water system. Application in an open water circuit can lead to excessive corrosion
of the water piping.
Example：
5
4
4.2
4.1
10
FHL1 FHL2 FHLn
19
20
Indoor
Outdoor
1
15
16
14
12
14
Modbus
16
Coding
Assembly unit
Coding
Assembly unit
1
Outdoor unit
7
2
15
Shut-off valve (Field supply)
4
User interface(accessory)
9
Filling valve (Field supply)
4.1
Balance tank (Field supply)
19
Drainage valve (Field supply)
4.2
Automatic bleed valve
11
Collector/distributor (Field supply)
5
Drainage valve
10
P_o: Outside circulation
pump
(Field supply)
Expansion vessel(field supply)
12
FHL
1…n
Floor heating loop (Field supply)
Filter (Accessory)
Bypass valve (field supply)
14
16
20
2
