Midea M-thermal Mono Series - Main Control Board of Hydraulic Module

21
9.3.1 Main control board of hydraulic module
12/14/16kW(1-phase)
Main control board of hydraulic module
Filter board(PCB C)(at back of the
PCB B,only for 3 phase unit)
12/14/16kW(3-phase)
Main control board of hydraulic module
Inverter module
control board(PCB A)
Main control board
of heat pump sysem(PCB B)
Inverter module
control board(PCB A)
Main control board
of heat pump sysem(PCB B)
