ANNEX K:

To install the E-heating tape at the drainage outlet (by client)

Connect the wireCeating tape at the drainage outlet to the wire joint XT3.

XT3

To the heating

tape of drainage

outlet

4/6kW

XT3

To the heating

tape of drainage

outlet

8/10kW
