30
Chapter 10: Printing Test Results EXP-800
If you are using the EXP internal printer, keep the clamps
connected to the battery during the printing process. After a
test the results automatically print.
NOTE: When the option TRACK CALLS is enabled,
the EXP writes the results to the data card.
To print a second copy of the results:
1. Press the PRINT soft key.
2. Select the language for the printed results. Use the UP/
DOWN ARROWS to move the dot to the option button of
your choice (1, 2, or 3).
1 ENGLISH
2 ESPAÑOL
3 FRANÇAIS
3. Press the NEXT soft key to continue.
Changing the Paper in the Internal Printer
The internal printer is shipped with a roll of thermal printing
paper installed in the paper compartment. The roll size is 2-1/4
inches wide by 1-7/8 inch in diameter. Replacement rolls are
available at most oce supply stores.
The analyzer uses only thermal printing paper. Below are four
major oce supply stores that carry thermal paper:
Store Part Number Phone
Ofce Depot 209-653-271 800-463-3768
Ofce Max 20121146 800-283-7674
Quill 856607 800-789-1331
Staples 531236 800-378-2753
NOTE: Due to production variances some paper
roll diameters may be too large. Please remove
paper from roll to recommended 1-7/8 inch di-
ameter. DO NOT force cover to close if roll is too
large.
To replace the paper roll:
1. Unlock the printer door by gently pressing down on the
red lever.
2. Lift the printer door and remove the spent roll.
Push the lever in this direction
Paper sensor
3. Place a new roll of paper in the compartment. As the dia-
gram in the paper compartment indicates, the paper feeds
from the bottom of the roll.
4. Pull the paper forward so that it extends past the serrated
edge of the paper slot.
5. Close the door and make sure the lever locks securely. For
a clean tear, pull the paper along the serrated edge. Do
not pull the paper straight out of the printer.
Chapter 10: Printing Test Results
